SBTL8000 / SBTL8200

SUS304 Stainless steel case ensures long-lasting durability. Ergonomic design makes card, fingerprint, and face authentication fast & simple for users. Factory tested. High quality electrical components and safety features.

Design a project

Category :

FEATURES

  • Biometric Authentication: Advanced biometric sensors allow for secure access control using fingerprints, facial recognition, or iris scanning, ensuring only authorized personnel can enter.
  • Contact-less Access: Incorporates RFID card readers or NFC technology for hassle-free access, minimizing physical contact and enhancing user convenience.
  • Safety and Security: The turnstile not only prevent unauthorized people entry also standard with emergency mode that allow people feel free egress under power off/fire alarm situations.
  • Customizable Configurations: Offers flexibility in lane width, direction control, and passage modes to accommodate various access control requirements and site layouts
  • High Throughput: Designed for high-traffic environments, capable of processing a large number of users efficiently without compromising security or causing congestion.
  • Ultra Comfortable Experience: quiet and stable movement let user feel free apprehension pass through
  • Wider Range Lane Type : provide 4 kinds of barrier size for optional, taking ADA and high security into account.
  • Emergency Egress Options: Equipped with emergency model or fail-safe mechanisms to allow for quick evacuation during emergencies while maintaining security protocols.

SPECIFICATIONS

Specification SBTL8000 SBTL8200
Power Requirements AC 100–120V / 200–240V, 50/60Hz AC 100–120V / 200–240V, 50/60Hz
Working Temperature -20°C to 60°C / -4°F to 140°F -20°C to 60°C / -4°F to 140°F
Working Humidity 5% – 95% 5% – 95%
Working Power 100W running / 30W standby 100W running / 30W standby
Working Environment Indoor / Outdoor (if shelter available) Indoor / Outdoor (if shelter available)
Throughput Rate < 35 people/min < 35 people/min
Lane Width 660mm (option 920mm) / 26in (36in) 660mm (option 920mm) / 26in (36in)
Noise < 60dB < 60dB
Infrared Sensor 10 pairs 10 pairs
Barrier Movement Swing Swing
MCBF ≥ 10 million ≥ 10 million
Drive Unit DC servo motor DC servo motor
LED Indicator Red / Green Red / Green
Emergency Mode Door open automatically Door open automatically
Chassis Dimensions (L×W×H) 1600×120×1041mm 1600×120×1041mm
Package Dimensions (L×W×H) 1700×600×1300mm 1700×300×1300mm
Net Weight 130kg / 286lbs 86kg / 190lbs
Gross Weight 150kg / 330lbs 100kg / 220lbs
Cabinet Material Stainless Steel 304 Stainless Steel 304
Lid Material Acrylic / Stainless Steel Acrylic / Stainless Steel
Barrier Material Acrylic Acrylic
Packing Material Wooden Case Wooden Case

DATASHEET

BIM

2024 Download

2025 Download

2026 Download

WARRANTY

ZKTeco USA Turnstiles have a 5-year limited hardware warranty against manufacturing defects.
